6 DIGITAL INPUTS AND OUTPUTS
APPLICATION: Digital inputs are used to control the instrument and the digital outputs can be used to control
gates, valves etc. or to produce alarm.
RELATED PARAMETERS: Sub-blocks 35- and 36-.
The weighing indicator has 4 digital inputs and 5 digital outputs if equipped with any option board. You may
enter set point values of the item after pressing key or you may recall them from Memory. Set
Memory has 500 pcs item record capacity, and each item has 5 set point values.
Refer to section 11, page 76 for technical details on Digital Inputs / Outputs including their connection.
Digital inputs and outputs are set to their functions in sub-blocks 35- and 36- . Digital inputs can be
programmed for zeroing, taring, print etc. in sub-block 35-. Digital outputs can be programmed for the
different functions as described below.
The digital inputs and outputs are programmable to use them as a Remote IO of PLC via fieldbus additional
tank, conveyor control, solenoid control, alarm etc.
The input and outputs are configurable as indicated in the table below.
In / Out
Descriptions
Related
parameter
Input 1
Zeroing, Taring, Clear, Print, Key lock, Remote Input of the PLC via Fieldbus.
351
Input 2
Zeroing, Taring, Clear, Print, Key lock, Remote Input of the PLC via Fieldbus.
352
Input 3
Zeroing, Taring, Clear, Print, Key lock, Remote Input of the PLC via Fieldbus.
353
Input 4
Zeroing, Taring, Clear, Print, Key lock, Remote Input of the PLC via Fieldbus.
354
Output 1
Set point1, Zero Range, Stable, Error, Remote output of the PLC via fieldbus.
361
Output 2
Set point2, Zero Range, Stable, Error, Remote output of the PLC via fieldbus.
362
Output 3
Set point3, Zero Range, Stable, Error, Remote output of the PLC via fieldbus.
363
Output 4
Set point4, Zero Range, Stable, Error, Remote output of the PLC via fieldbus.
364
Output 5
Set point5, Zero Range, Stable, Error, Remote output of the PLC via fieldbus.
365
Digital inputs and outputs are set to their functions in sub-blocks 35- and 36-. Digital inputs can be
programmed for zeroing, taring, print etc. in sub-block 35-. Digital outputs can be programmed for the
different functions as described below.
