9 DIGITAL LOAD CELLS (DLC)
For the pin configuration of the digital load cells RC3D please see page 20. It is possible to connect all RC3D
load cells to the terminal and address them later.
9.1 ADDRESSING OF DIGITAL LOAD CELLS
IMPORTANT NOTE: For addressing all digital load cells RC3D can be connected.
The following diagram shows the recommended load cell addressing principle. Remember, if pair shift
adjustment is selected, 1 and 2, 3 and 4 etc. will be sectional pairs.
Figure 9.1 - The addressing principle of RC3D.
Addressing of RC3D digital load cells
1. Press key at the [ 533 ADDRESSING ] prompt to start the addressing.
2. The message [ WAIT ] appears for a short time and then [ DLC NUMBER :01 ] appears. Here 01 is
the address of the DLC.
3. Press key to enter the serial number of the first DLC.
4. After the [ SERIAL: ] prompt appears, type the serial number by pressing key to increase
or key to decrease the blanking digit and press key to select the next digit.
5. Press key to start addressing of the digital load cell. [ ADDRESSING DLC ] message
appears on the display for 10 seconds while addressing is being performed.
6. The next DLC number appears on the display. Press key to enter the serial number and
repeat from item 4 until all DLCs have been addressed.
7. [ 532 QUANTITY :XY ] message appears after addressing of all load cells.
8. Press press key until [ SAVE : YES ]
prompt appears on the display and press key to save the changes.
IMPORTANT NOTE: If the [E81 CANNOT ADDR] error message comes across during addressing, set the digital
load cell to its default settings, and try addressing again. Refer to Parameter 995 .
Addressing of RC3D digital load cells manually
The manual addressing helps to change any load cell or to change the instrument without performing shift
adjustment and calibration. To address any load cell manually,
1. Press key at the [ 533 ADDRESSING ] prompt to start the addressing.
2. The message [ WAIT ] appears for a short time and then [ DLC NUMBER :01 ] message appears
to indicate load cell address.
3. Press key until the address of the new load cell to be installed appears.
4. Connect the new load cell.
5. Press key to start addressing of the load cell.
6. Enter the serial number of the load cell by pressing key to increase or key to decrease
the blanking digit and press key to select the next digit. Press key to address the load
cell.
7. After the following DLC number has appeared on the display, press key and
the message [ 532 QUANTITY :XY ] appears.
1
2
3
10
9
8
7
5
6
4
Pair 1
Pair 2
Pair 5
