Flintec FT-111 - Fast Continuous Data Output; Print Mode

FT-111, User Manual Rev. 2.0.0, June 2022 Page 40 of 137
Calculation of the checksum
CHK (Checksum) = 0 ( STX + STATUS A + ..... + LF )
Error Messages: UNDER, OVER, A.OUT, L-VOLT and TILT are represented in Indicated data fields.
Note: The weight data is represented with right aligned and the error messages are represented with left
aligned.
7.2 FAST CONTINUOUS DATA OUTPUT
fast. The output rate is related with the baud rate. Use higher baud rate for faster data rate. CR and LF can be
enabled. You may reduce the data transfer speed by increasing the delay between data output packages.
The data format of the fast continuous data output is;
[STX][STATUS][SIGN][WEIGHT VALUE][CR][LF]
Examples:
S+000123.4 (weight is stable and 123.4)
D+000123.4 (weight is unstable and 123.4)
+ (Over load)
- (Under load)
O (ADC out error)
7.3 PRINT MODE
The format of the data output in Print mode can be selected in 5 different type forms in the sub-block 16- .
Only one serial port can be programmed for printing. Print mode data outputs is sent by pressing the
key or by receiving ASCII P command via serial port, or via Ethernet port by setting remote IP and remote
port number, refer to parameter 19E and 19F.
SINGLE LINE
You can transmit the printout data in single line format by pressing key. This format is recommended to
send the print data to PC or to any host. The data output structure is;
CN: 71 G: 3.007kg T: 1.001kg N: 2.006kg *ALB: 5*
DAT
E
TIM
E
CN
GRO
SS
TAR
E
NET
ALB
C
R
L
F
10
3
5
3
9
3
13
3
13
3
13
4
12
1
1
