FT-111, User Manual Rev. 2.0.0, June 2022 Page 7 of 137
Standard applications
Labelling with barcode, free set points, functional digital outputs, livestock
weighing, Remote IO of PLC or HMI, fieldbus interface.
Memory
Application memories
Set Memory to save limit values at your industrial weighing.
Memory size is 500 item records.
Alibi memory (optional)
99 999 records
Communication
Connectable with
PC, PLC, Printer, Remote display, EPL printer etc.
RS 232
Port
2 pieces opto-isolated, 3 wire.
Baud rate
1200 to 57600 programmable
Data
Length 7 or 8 bits; parity even, odd or none
RS 485
Baud rate
1200 to 57600 programmable
Data
Length 7 or 8 bits; parity even, odd or none
Stations
Up to 31 stations
Ethernet TCP/IP
Transmission
rate
10 / 100 Mbit/s, Full duplex
TCP/IP settings
Manual IP assign over EtherX PC Software or by keys in programming mode.
Connection
method
Server or Client
Installation
Switched Ethernet transmission with shielded twisted pair cables and RJ-45.
Isolation
Galvanically isolated bus electronics
Response speed
Max. 4 ms response delay after read/write commands
USB
Connection
Standard USB Mini-B cable
Response speed
Max. 4 ms response delay after read/write commands
Digital Inputs and Outputs (optional)
Digital Inputs
Opto-isolated 4 digital input, 12 to 28 VDC, 10mA
Digital Outputs
5 free relay contact, 250 VAC or 30 VDC, 0.2A
Analogue Output (optional)
Voltage output
0-5 VDC, 0-10 VDC
Current output
4-20mA, 0-20mA
Resolution
60 000 steps between minimum and maximum output.
Max. cable length
300 meters
Max. load resistance
(current output)
500 Ω
Min load resistance
(voltage output)
10 kΩ
Profibus DPV1 (optional)
Data rate
Up to 12000 kbit/s with automatic baud rate detection
GSD file
Generic GSD-file provided
