Device Functions Proline Promass 83 7 Block OUTPUTS
7.3 Group RELAY OUTPUT (1...2)
7.3.1 Function group CONFIGURATION
OUTPUTS E

CURRENT OUTPUT 1 EAA

CURRENT OUTPUT 2 EAB

CURRENT OUTPUT 3 EAC

PULSE/FREQ. OUTPUT 1 ECA

PULSE/FREQ. OUTPUT 2 ECB

RELAY OUTPUT 1 EGA

CONFIGURATION 470

RELAY OUTPUT 2 EGB

CONFIGURATION 470
Function description
OUTPUTS o RELAY OUTPUT (1...2) o CONFIGURATION
ASSIGN RELAY
(4700)
Use this function to assign a switching function to the relay output.
Options (standard):
OFF
ON (operation)
FAULT MESSAGE
NOTICE MESSAGE
FAULT MESSAGE or NOTICE MESSAGE
EPD (Empty pipe detection, only if active)
FLOW DIRECTION
LIMIT MASS FLOW
LIMIT VOLUME FLOW
LIMIT CORRECTED VOLUME FLOW
LIMIT DENSITY
LIMIT REFERENCE DENSITY
LIMIT TEMPERATURE
LIMIT TOTALIZER 1...3
Advanced options with optional software package BATCHING:
BATCH VALVE 1 (e.g. to control valve 1)
BATCH VALVE 2 (e.g. to control valve 2)
BATCH RUNNING
> BATCH TIME
>< BATCH QUANTITIES (< min. / > max. batching quantity)
PROGRESS NOTE (batching end approaching)
! Note!
• The batching valves defined in the function BATCH STAGES (7208) are the only
available selection (max. 3).
• The only options available are the monitoring functions (7240 to 7243) which have a
value not equal to zero (max. 3).
(continued on next page)
