FMC Technologies Proline Promass 83 E - Function Group ELECTRODYNAMIC SENSORS

Issue/Rev. 0.2 (12/12) MN0M023 • Page 173
Device Functions Proline Promass 83 10 Block SPECIAL FUNCTION
10.3.8 Function group ELECTRODYNAMIC SENSORS
SPECIAL FUNCTION H

ADVANCED DIAGNOSIS HEA

CONFIGURATION 740

ACQUISITION 741

MASS FLOW 742

DENSITY 743

REFERENCE DENSITY 744

TEMPERATURE 745

TUBE DAMPING 746

ELEC.-DYN. SENSORS 747
Function description
SPECIAL FUNCTION o ADVANCED DIAGNOSIS o ELECTRODYNAMIC SENSORS
REFERENCE VALUE
ELECTRODYNAMIC
SENSORS
(7470)
The reference value for the electrodynamic sensors appears on the display.
Display:
5-digit floating-point number
ELECTRODYNAMIC
SENSORS
(7471)
The measuring values for the electrodynamic sensors appear on the display.
Display:
5-digit floating-point number
MINIMUM VALUE
(7472)
The lowest value of the electrodynamic sensors since the saved values were last reset
appears on the display.
Display:
5-digit floating-point number
MAXIMUM VALUE
(7473)
The highest value of the electrodynamic sensors since the saved values were last reset
appears on the display.
Display:
5-digit floating-point number
ELECTRODYNAMIC
SENSOR HISTORY
(7474)
The last ten values of the electrodynamic sensors since the saved values were last reset
appear on the display.
Display:
5-digit floating-point number
ELECTRODYNAMIC
SENSOR DEVIATION
(7475)
This function displays the deviation between the measuring values for the electrodynamic
sensors and the reference values (FACTORY or USER), see page 166, selected in the
function SELECT REFERENCE CONDITION (7402) is displayed.
Display:
5-digit floating-point number
