3 Block MEASURED VARIABLES Device Functions Proline Promass 83
UNIT VOLUME FLOW
(0402)
Use this function to select the unit for displaying the volume flow (volume/time).
The unit you select here is also valid for:
• Current outputs
• Frequency outputs
• Relay switch points (limit value for volume flow, flow direction)
• Low flow cut off
Options:
Metric:
Cubic centimeter o cm
3
/s; cm
3
/min; cm
3
/h; cm
3
/day
Cubic decimeter o dm
3
/s; dm
3
/min; dm
3
/h; dm
3
/day
Cubic meter o m
3
/s; m
3
/min; m
3
/h; m
3
/day
Milliliter o ml/s; ml/min; ml/h; ml/day
Liter o l/s; l/min; l/h; l/day
Hectoliter o hl/s; hl/min; hl/h; hl/day
Megaliter o Ml/s; Ml/min; Ml/h; Ml/day
US:
Cubic centimeter o cc/s; cc/min; cc/h; cc/day
Acre foot o af/s; af/min; af/h; af/day
Cubic foot o ft
3
/s; ft
3
/min; ft
3
/h; ft
3
/day
Fluid ounce o oz f/s; oz f/min; oz f/h; oz f/day
Gallon o gal/s; gal/min; gal/h; gal/day
Kilogallon o Kgal/s; Kgal/min; Kgal/h; Kgal/day
Million gallon o Mgal/s; Mgal/min; Mgal/h; Mgal/day
Barrel (normal fluids: 31.5 gal/bbl) o bbl/s; bbl/min; bbl/h; bbl/day
Barrel (beer: 31.0 gal/bbl) o bbl/s; bbl/min; bbl/h; bbl/day
Barrel (petrochemicals: 42.0 gal/bbl) o bbl/s; bbl/min; bbl/h; bbl/day
Barrel (filling tanks: 55.0 gal/bbl) o bbl/s; bbl/min; bbl/h; bbl/day
Imperial
Gallon o gal/s; gal/min; gal/h; gal/day
Mega gallon o Mgal/s; Mgal/min; Mgal/h; Mgal/day
Barrel (beer: 36.0 gal/bbl) o bbl/s; bbl/min; bbl/h; bbl/day
Barrel (petrochemicals: 34.97 gal/bbl) o bbl/s; bbl/min; bbl/h; bbl/day
For arbitrary units (see function TEXT ARBITRARY VOLUME on page 23)
_ _ _ _ o _ _ _ _/s; _ _ _ _/min; _ _ _ _/h; _ _ _ _/day
Factory setting:
Country-dependent (m
3
/h or US-Mgal/day)
! Note!
If you defined a unit of volume in the ARBITRARY UNIT 060 function group (see
page 22) the unit in question is shown here.
UNIT VOLUME
(0403)
Use this function to select the unit for displaying the volume.
The unit you select here is also valid for: Pulse weighting (e.g. m
3
/p)
Options:
Metric o cm
3
; dm
3
; m
3
; ml; l; hl; Ml Mega
US o cc; af; ft
3
; oz f; gal; Kgal; Mgal; bbl (normal fluids); bbl (beer);
bbl (petrochemicals) o bbl (filling tanks)
Imperial o gal; Mgal; bbl (beer); bbl (petrochemicals)
For free selectable units o _ _ _ _ (see function TEXT ARBITRARY VOLUME on
page 23)
Factory setting:
m
3
! Note!
• If you defined a unit of volume in the ARBITRARY UNIT 060 function group
(see page 22) the unit in question is shown here.
• The unit of the totalizers is independent of your choice here. The unit for each
totalizer is selected separately for the totalizer in question.
Function description
MEASURED VARIABLES o SYSTEM UNITS o CONFIGURATION
