FMC Technologies Proline Promass 83 E - Function Group ADDITIONAL CONFIGURATION

Issue/Rev. 0.2 (12/12)
Page 20 • MN0M023
3 Block MEASURED VARIABLES Device Functions Proline Promass 83
3.2.2 Function group ADDITIONAL CONFIGURATION
MEASURED
VARIABLES
A

MEASURING VALUES AAA

SYSTEM UNITS ACA

CONFIGURATION 040

ADD. CONFIGURATION 042
Function description
MEASURED VARIABLES o SYSTEM UNITS o ADDITIONAL CONFIGURATION
UNIT DENSITY
(0420)
Use this function to select the unit for displaying the fluid density.
The unit you select here is also valid for:
• Current outputs
• Frequency outputs
• Relay switch points (limit value for density)
• Density response value for EPD
• Density adjustment value
Options:
Metric o g/cm
3
; g/cc; kg/dm
3
; kg/l; kg/m
3
; SD 4 °C, SD 15 °C, SD 20 °C;
SG 4 °C, SG 15 °C, SG 20 °C
US o lb/ft
3
; lb/gal; lb/bbl (normal fluids); lb/bbl (beer); lb/bbl (petrochemicals); lb/bbl
(filling tanks)
Imperial o lb/gal; lb/bbl (beer); lb/bbl (petrochemicals)
Factory setting:
kg/l
SD = Specific Density, SG = Specific Gravity
The specific density is the ratio of fluid density to water density
(at water temperature = 4, 15, 20 °C).
UNIT REFERENCE
DENSITY
(0421)
Use this function to select the unit for displaying the reference density.
The unit you select here is also valid for:
• Current outputs
• Frequency outputs
• Relay switch points (limit value for density)
• Fixed reference density (for calculation of corrected volume flow)
• Current input (read in the reference density via current input)
Options:
Metric:
kg/Nm
3
kg/Nl
US:
g/Scc
kg/Sm
3
lb/Scf
Factory setting:
kg/Nl
