Device Functions Proline Promass 83 5 Block USER INTERFACE
ASSIGN
(continued)
Advanced options with optional software package BATCHING:
BATCHING KEYS (softkeys on the local display)
! Note!
• If you select the BATCHING OPERATING KEYS, the multiplex display functionality
(function ASSIGN (2620), etc.) is not available in the information line.
• For information on the functional concept of the batching menu, See Operating
Instructions Proline Promass 83, BA 059D/06/en/, chapter Operation.
Advanced options with optional software package CONCENTRATION:
TARGET MASS FLOW
% TARGET MASS FLOW
TARGET VOLUME FLOW
% TARGET VOLUME FLOW
CORRECTED TARGET VOLUME FLOW
CARRIER MASS FLOW
% CARRIER MASS FLOW
CARRIER VOLUME FLOW
% CARRIER VOLUME FLOW
CORRECTED CARRIER VOLUME FLOW
% BLACK LIQUOR
°BAUME
°API
°PLATO
°BALLING
°BRIX
OTHERS (_ _ _ _ flexible concentration)
Advanced options with optional software package ADVANCED DIAGNOSIS:
MASS FLOW DEVIATION
DENSITY DEVIATION
REFERENCE DENSITY DEVIATION
TEMPERATURE DEVIATION
TUBE DAMPING DEVIATION
ELECTRODYNAMIC SENSOR DEVIATION
OPERATING FREQUENCY FLUCTUATION DEVIATION
TUBE DAMPING FLUCTUATION DEVIATION
100% VALUE
(2601)
! Note!
This function is not available unless one of the following was selected in the ASSIGN
function (2600):
• MASS FLOW IN %
• VOLUME FLOW IN %
• CORRECTED VOLUME FLOW IN %
• MASS FLOW BARGRAPH IN %
• VOLUME FLOW BARGRAPH IN %
• CORRECTED VOLUME FLOW BARGRAPH IN %
Use this function to define the flow value to be shown on the display as the 100% value.
User input:
5-digit floating-point number
Factory setting:
10 kg/s, 10 l/s or 10 Nl/s
Function description
USER INTERFACE o INFORMATION LINE o CONFIGURATION
