9 Block BASIC FUNCTION Device Functions Proline Promass 83
9.1 Group HART
9.1.1 Function group CONFIGURATION
BASIC FUNCTION G

HART GAA

CONFIGURATION 600
Function description
BASIC FUNCTION o HART o CONFIGURATION
TAG NAME
(6000)
Use this function to enter a tag name for the measuring device. You can edit and read this
tag description via the local display or the HART protocol.
User input:
max. 8-character text, permissible: A-Z, 0-9, +, –, punctuation marks
Factory setting:
“_ _ _ _ _ _ _ _” (no text)
TAG DESCRIPTION
(6001)
Use this function to enter a tag description for the measuring device. You can edit and
read this tag description via the local display or the HART protocol.
User input:
max. 16-character text, permissible: A-Z, 0-9, +, –, punctuation marks
Factory setting:
“_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _” (No text)
BUS ADDRESS
(6002)
Use this function to define the address for the exchange of data with the HART protocol.
User input:
0...15
Factory setting:
0
! Note!
Addresses 1...15: a constant 4 mA current is applied.
HART PROTOCOL
(6003)
Use this function to display if the HART protocol is active.
Display:
OFF = HART protocol not active
ON = HART protocol active
! Note!
The HART protocol can be activated with the selection 4-20 mA HART or
4-20 mA (25 mA) HART in the function CURRENT SPAN, (see page 64).
WRITE PROTECTION
(6004)
Use this function to check whether the measuring device can be write-accessed.
Display:
OFF = Data exchange is possible
ON = Data exchange disabled
Factory setting:
OFF
! Note!
Write protection is activated and deactivated by means of a jumper on the I/O module
(see Operating Instruction Proline Promass 83, BA 059D/06/en).
