Device Functions Proline Promass 83 10 Block SPECIAL FUNCTION
CALCULATION MODE
(7206)
! Note!
This function is only available if MODE 1 or MODE 2 was selected in the
COMPENSATION MODE function (7206).
Use this function to select the method for calculating the recorded after run quantities.
Options:
ALL
All after run quantities are used in the calculation.
SELECTION
The after run quantities recorded are filtered. The smallest and largest after run quantity
are not taken into account in the calculation (extreme value filter).
Factory setting:
ALL
! Note!
Machine-related (larger) “extreme values”, occurring especially at startup, delay
correction and distort real reproducibility. By selecting “SELECT”, these “extreme
values” are not taken into account.
Example:
Function CALCULATION MODE (7206) = SELECTION
Function AVERAGING DRIP (7207) = 5
From five after run quantities recorded, the largest and smallest are not used. From the
remaining three after run quantities, an average after run quantity is calculated which is
taken into account at the next batching.
AVERAGING DRIP
(7207)
! Note!
This function is only available if MODE 1 or MODE 2 was selected in the
COMPENSATION MODE function (7206).
Use this function to specify the number of after run quantities (cycles) which are included
in calculating the batching compensation mode, MODE 1 or MODE 2.
! Note!
The value entered in this function influences the measuring system reaction time.
If you specify:
• a small calculation depth (low value entered) = measuring system reacts quickly to
differing amount of after run quantities.
• a large calculation depth (high value entered) = measuring system reacts slowly to
changing after run quantities.
User input:
0...100
Factory setting:
0 [cycles]
Function description
SPECIAL FUNCTION o BATCHING FUNCTION o CONFIGURATION
