Issue/Rev. 0.2 (12/12)
Page 54 • MN0M023
5 Block USER INTERFACE Device Functions Proline Promass 83
ASSIGN
(continued)
Advanced options with optional software package CONCENTRATION:
TARGET MASS FLOW
% TARGET MASS FLOW
TARGET VOLUME FLOW
% TARGET VOLUME FLOW
CORRECTED TARGET VOLUME FLOW
CARRIER MASS FLOW
% CARRIER MASS FLOW
CARRIER VOLUME FLOW
% CARRIER VOLUME FLOW
CORRECTED CARRIER VOLUME FLOW
% BLACK LIQUOR
°BAUME
°API
°PLATO
°BALLING
°BRIX
OTHERS (_ _ _ _ flexible concentration)
Advanced options with optional software package ADVANCED DIAGNOSIS:
MASS FLOW DEVIATION
DENSITY DEVIATION
REFERENCE DENSITY DEVIATION
TEMPERATURE DEVIATION
TUBE DAMPING DEVIATION
ELECTRODYNAMIC SENSOR DEVIATION
OPERATING FREQUENCY FLUCTUATION DEVIATION
TUBE DAMPING FLUCTUATION DEVIATION
! Note!
Multiplex mode is suspended as soon as a fault / notice message is generated. The
message in question appears on the display.
• Fault message (identified by a lightning icon):
– If “ON” was selected in the ACKNOWLEDGE FAULTS (8004)
function, multiplex mode is continued as soon as the fault has been acknowledged
and is no longer active.
– If “OFF” was selected in the ACKNOWLEDGE FAULTS (8004)
function, multiplex mode is continued as soon as the fault is no longer active.
• Notice message (identified by an exclamation mark):
– Multiplex mode is continued as soon as the notice message is no longer active.
100% VALUE
(2621)
! Note!
This function is not available unless one of the following was selected in the ASSIGN
function (2620):
• MASS FLOW IN %
• VOLUME FLOW IN %
• CORRECTED VOLUME FLOW IN %
• MASS FLOW BARGRAPH IN %
• VOLUME FLOW BARGRAPH IN %
• CORRECTED VOLUME FLOW BARGRAPH IN %
Use this function to define the flow value to be shown on the display as the 100% value.
User input:
5-digit floating-point number
Factory setting:
10 kg/s, 10 l/s or 10 Nl/s
Function description
USER INTERFACE o INFORMATION LINE o MULTIPLEX
