8 Block INPUTS Device Functions Proline Promass 83
8.1 Group STATUS INPUT
8.1.1 Function group CONFIGURATION
INPUTS F

STATUS INPUT FAA

CONFIGURATION 500
Function description
INPUTS o STATUS INPUT o CONFIGURATION
ASSIGN STATUS INPUT
(5000)
Use this function to assign a switching function to the status input.
Options:
OFF
RESET TOTALIZER 1
RESET TOTALIZER 2
RESET TOTALIZER 3
RESET ALL TOTALIZERS
POSITIVE ZERO RETURN
RESET FAULT MESSAGE
ZEROPOINT ADJUSTMENT
Advanced options with optional software package BATCHING:
RUN BATCHING (start/stop)
HOLD BATCHING (stop/continue)
RESET BATCH SUM (resetting total quantity / total quantity totalizers)
RESET TOTALIZER 3 & START BATCHING (reset of totalizer 3, followed by start)
" Caution!
If an input pulse is sent during a batching process, the batching process is canceled
immediately, but totalizer 3 is not reset. This allows the partial filling to be read out
correctly.
Advanced options with optional software package ADVANCED DIAGNOSIS:
ACQUISITION
! Note!
This function is not available unless the SINGLE SHOT setting is selected in the
ACQUISITION MODE function (7410).
Factory setting: OFF
" Caution!
POSITIVE ZERO RETURN is active as long as the level is available at the status input
(continuous signal). All other assignments react to a change in level (pulse) at the status
input.
ACTIVE LEVEL
(5001)
Use this function to define whether the assigned function (see function ASSIGN STATUS
INPUT) is released when the signal level is present (HIGH) or not present (LOW).
Options:
HIGH
LOW
Factory setting: HIGH
MINIMUM
PULSE WIDTH
(5002)
Use this function to define a minimum pulse width which the input pulse must achieve in
order to trigger the selected switching function, (see function ASSIGN STATUS INPUT
(5000)).
User input:
20...100 ms
Factory setting: 50 ms
