Device Functions Proline Promass 83 3 Block MEASURED VARIABLES
3.2 Group SYSTEM UNITS
3.2.1 Function group CONFIGURATION
MEASURED
VARIABLES
A

MEASURING VALUES AAA

SYSTEM UNITS ACA

CONFIGURATION 040
Function description
MEASURED VARIABLES o SYSTEM UNITS o CONFIGURATION
You can select the units for measured variables in this function group.
UNIT MASS FLOW
(0400)
Use this function to select the unit for displaying the mass flow (mass/time).
The unit you select here is also valid for:
• Current outputs
• Frequency outputs
• Relay switch points (limit value for mass flow, flow direction)
• Low flow cut off
Options:
Metric:
gram o g/s; g/min; g/h; g/day
kilogram o kg/s; kg/min; kg/h; kg/day
ton o t/s; t/min; t/h; t/day
US:
ounce o oz/s; oz/min; oz/h; oz/day
pound o lb/s; lb/min; lb/h; lb/day
ton o ton/s; ton/min; ton/h; ton/day
For arbitrary units (see function TEXT ARBITRARY MASS on page 22)
_ _ _ _ o _ _ _ _/s; _ _ _ _/min; _ _ _ _/h; _ _ _ _/day
Factory setting:
Country-dependent (kg/h or US-lb/min)
! Note!
If you defined a unit of mass in the ARBITRARY UNIT 060 function group (see page 22)
the unit in question is shown here.
UNIT MASS
(0401)
Use this function to select the unit for displaying the mass.
The unit you select here is also valid for:
• Pulse value (e.g. kg/p)
Options:
Metric o g; kg; t
US o oz; lb; ton
For free selectable units o _ _ _ _ (see function TEXT ARBITRARY MASS on page 22)
Factory setting:
Country-dependent (kg or US-lb)
! Note!
• If you defined a unit of mass in the ARBITRARY UNIT 060 function group
(see page 22) the unit in question is shown here.
• The unit of the totalizers is independent of your choice here. The unit for each
totalizer is selected separately for the totalizer in question.
