FMC Technologies Proline Promass 83 E - Switching Behavior of the Relay Output

Issue/Rev. 0.2 (12/12) MN0M023 • Page 109
Device Functions Proline Promass 83 7 Block OUTPUTS
7.3.5 Switching behavior of the relay output
Function State Relay coil
Contact*
NC NO
ON (operation) System in measuring mode
A0001052
energized
A0001239 A0001237
System not in measuring mode
(power supply failed)
A0001291
de-energized
A0001240 A0001238
Fault message System OK
A0001052
energized
A0001239 A0001237
(System or process error)
Fault oFailsafe mode, outputs
/
Inputs and totalizers
A0001291
de-energized
A0001240 A0001238
Notice message System OK
A0001052
energized
A0001239 A0001237
(System or process error)
Fault o Continuation of
measuring
A0001291
de-energized
A0001240 A0001238
Fault message
or
Notice message
System OK
A0001052
energized
A0001239 A0001237
(System or process error)
Fault o Failsafe mode
or
Note o Continuation of
measuring
A0001291
de-energized
A0001240 A0001238
Esc
E
+
-
XXX.XXX.XX
Esc
E
+
-
XXX.XXX.XX
Esc
E
+
-
XXX.XXX.XX
Esc
E
+
-
XXX.XXX.XX
Esc
E
+
-
XXX.XXX.XX
Esc
E
+
-
XXX.XXX.XX
Esc
E
+
-
XXX.XXX.XX
Esc
E
+
-
XXX.XXX.XX
