10 Block SPECIAL FUNCTION Device Functions Proline Promass 83
10.3.5 Function group REFERENCE DENSITY
SPECIAL FUNCTION H

ADVANCED DIAGNOSIS HEA

CONFIGURATION 740

ACQUISITION 741

MASS FLOW 742

DENSITY 743

REFERENCE DENSITY 744
Function description
SPECIAL FUNCTION o ADVANCED DIAGNOSIS o REFERENCE DENSITY
! Note!
The appropriate unit is taken from the function UNIT REFERENCE DENSITY (0421) ( page 20).
REFERENCE VALUE
REFERENCE DENSITY
(7440)
The reference value for the reference density appears on the display.
Display:
5-digit floating-point number, incl. units
REFERENCE DENSITY
(7441)
The measured reference density appears on the display.
Display:
5-digit floating-point number, incl. units
MINIMUM VALUE
(7442)
The lowest reference density value since the saved values were last reset appears on the
display.
Display:
5-digit floating-point number, incl. units
MAXIMUM VALUE
(7443)
The highest reference density value since the saved values were last reset appears on the
display.
Display:
5-digit floating-point number, incl. units
REFERENCE DENSITY
HISTORY
(7444)
The last ten reference density values since the saved values were last reset appear on the
display.
Display:
5-digit floating-point number, incl. units
REFERENCE DENSITY
DEVIATION
(7445)
This function displays the deviation between the measured reference density and the
reference values (FACTORY or USER), see page 166, selected in the function SELECT
REFERENCE CONDITION (7402).
Display:
5-digit floating-point number, incl. units
WARNING LEVEL
(7446)
! Note!
This function is not available unless ON was selected in the WARNING MODE function
(7403).
Use this function to specify a limit value for the reference density. A notice message is
generated if the limit value is exceeded.
User input:
0...99999 [%]
Factory setting:
100%
