Issue/Rev. 0.2 (12/12) MN0M023 • Page 97
Device Functions Proline Promass 83 7 Block OUTPUTS
VALUE SIMULATION
FREQUENCY
(4303)
! Note!
This function is not available unless FREQUENCY was selected in the OPERATION
MODE function (4200) and the SIMULATION FREQUENCY function (4302) is active
(= ON).
Use this function to define a free selectable frequency value (e.g. 500 Hz) which should
be output at the frequency output (with maximum pulse frequency or shortened
minimum pulse width). This value is used to test downstream devices and the measuring
device itself.
User input:
0...12500 Hz
Factory setting:
0 Hz
" Caution!
The setting is not saved if the power supply fails.
Function description
OUTPUTS o PULSE/FREQUENCY OUTPUT (1...2) o OPERATION (FREQUENCY)
