The wire speed value can also be specified or changed in the Process mix para-
meters.
Alc
Arc length correction
Is taken from the welding parameters
Setting range: -10.0 - +10.0
The arc length correction value can also be specified or changed in the Process
mix parameters.
For CMT mix:
Positive correction:
increase in the pulsed voltage for the PMC phase
longer reverse movement in the CMT phase (increases arc length)
Negative correction:
reduction in the pulsed voltage for the PMC phase
shorter reverse movement in the CMT phase (reduces arc length)
PDc
Pulse/dynamic correction
Is taken from the welding parameters
Setting range: -10.0 - +10.0
The pulse/dynamic correction value can also be specified or changed in the Pro-
cess mix parameters.
For CMT mix:
Positive correction:
increase in the pulse energy (pulse current height, pulse current width)
Reduction in the pulse frequency in the PMC phase
Negative correction:
reduction in the pulse energy (pulse current height, pulse current width)
Increase in the pulse frequency in the PMC phase
Hptc (3)
Upper power time correction
To set the duration of the hot process phase in a mixed process
Setting range: -10.0 - +10.0
Factory setting: 0
Lptc (2)
Lower power time correction
To set the duration of the cold process phase in a mixed process
Setting range: -10.0 - +10.0
Factory setting: 0.0
Upper and lower power time correction is used to define the relationship
between hot and cold process phases.
If the lower power time correction is increased, the process frequency reduces
and the LSC process phase becomes longer.
