Fronius TPS/i COMPACT - 2-Step Mode

E
End arc length correction
SL2
Slope 2: the welding current is steadily lowered until it reaches the final current
GPo
Gas post-flow
SPt
Spot welding time
A detailed explanation of the parameters can be found in the section headed
"Process parameters".
2-step mode
t
I
+
I
GPr
GPo
"2-step mode" is suitable for
-
Tacking work
-
Short weld seams
-
Automated and robot welding
4-step mode
t
I
+
I
GPr GPo
+
"4-step mode" is suitable for longer weld seams.
78
