Fronius TPS/i COMPACT - Process Parameters for Synchropulse

Process para-
meters for Syn-
chroPulse
The following process parameters can be set for SynchroPulse welding:
Syn-Puls
SynchroPulse
To activate/deactivate SynchroPulse
Setting range: off / on
Factory setting: off
vd (1)
Wire speed
For setting the average wire speed and therefore the welding power for Syn-
chroPulse
Setting range: 1.0 - 25.0 m/min (40 - 985 ipm)
Factory setting: 5 m/min
dFd (2)
Delta wire feed
For setting the Delta wire feed:
with SynchroPulse, the set wire speed is alternately increased/decreased by the
Delta wire feed. The parameters concerned adapt themselves to this wire speed
acceleration/delay accordingly.
Setting range: 0.1 - 6.0 m/min (5 - 235 ipm)
Factory setting: 2.0 m/min
F (3)
Frequency
For setting the frequency for SynchroPulse
Setting range: 0.5 - 3.0 Hz
Factory setting: 3.0 Hz
DC (4)
Duty Cycle (high)
For weighting the duration of the higher operating point in a SynchroPulse period
Setting range: 10 - 90%
Factory setting: 50%
Al-h (5)
Arc length correction high
For correcting the arc length for SynchroPulse in the upper operating point (=
average wire speed plus Delta wire feed)
Setting range: -10.0 - +10.0
Factory setting: 0
- .... short arc
0 ... uncorrected arc length
+ ... longer arc
Al-l (6)
Arc correction low
For correcting the arc length for SynchroPulse in the lower operating point (= av-
erage wire speed less Delta wire feed)
Setting range: -10.0 - +10.0
Factory setting: 0
