Fronius TPS/i COMPACT - Stitch Welding

1
Hold the welding torch vertical
2
Press and release the torch trigger
3
Keep the welding torch in the same position
4
Wait for the gas post-flow time
5
Raise the welding torch
NOTE!
Pre-set start of welding and end of welding parameters are also active for spot
welding.
▶
A start of welding / end of welding action for spot welding can be stored in
the Setup menu under Process parameters / Start/End.
▶
If the final current time is active, the end of welding is not after the pre-set
spot welding time, but only once the pre-set slope and final current times
have ended.
Stitch welding
1
Select the desired welding process
2
Select the operating mode for stitch welding
3
Select the filler metal, wire diameter and shielding gas
4
Set the desired welding parameters depending on the selected welding pro-
cess
5
Activate stitch welding:
Setup menu / Process parameters / Interval / set Int. parameter to "on"
6
Set the other parameters for stitch welding:
Stitch welding time Int-t, interval break time Int-b, interval cycles Int-C,
7
Open the gas cylinder valve
8
Set the shielding gas flow rate
WARNING!
Danger due to emerging wire electrode.
This can result in serious personal injuries.
▶
Hold the welding torch so that the tip of the welding torch points away from
the face and body.
▶
Wear suitable protective goggles.
▶
Do not point the welding torch at people.
▶
Ensure that the wire electrode can only intentionally make contact with elec-
trically conductive objects.
9
Stitch welding
Procedure for stitch welding:
1
Hold the welding torch vertical
2
Depending on the selected mode:
press and hold the torch trigger (2-step mode)
press and release the torch trigger (4-step mode)
3
Keep the welding torch in the same position
4
Wait for the welding interval
5
Position the welding torch at the next point
