Retrieving sys-
tem data
1
Select Setup menu / Settings / View / System data
2
Press the right adjusting dial
The first available system data value is displayed.
3
Select the desired system data value by turning the right adjusting dial
4
To exit the Setup menu, press the "Welding process" and "Mode" buttons at
the same time
The following system data can be displayed:
IP
Current arc power in kW
The arc power is the product of welding current and welding voltage and is used
to calculate the electrical energy input:
E = IP / vs
E Electrical energy input in kJ/cm
IP Arc power in kW
vs Welding speed in cm/s
IE
Current arc energy in kJ
The arc energy is the sum total of the arc power and calculates the heat input of
the weld seam most recently produced.
If the weld seam length is known the electrical energy input can be calculated:
E = IE / L
E Electrical energy input in kJ/cm
IE Arc energy in kJ
L Length of the weld seam in cm
The arc energy is preferably used during manual welding.
I-M1
Current motor current in A, wirefeeder 1
(wirefeeder next to the arc)
I-M2
Current motor current in A, wirefeeder 2
(e.g. the rear wirefeeder in a push-pull system)
I-M3
Current motor current in A, wirefeeder 3
(e.g. an unreeling wirefeeder in a push-pull system with unreeling wirefeeder)
CFI
Current flow rate in l/min on the cooling unit
(with built-in OPT/i CU flow temperature sensor option)
Error output if flow rate < 0.7 l/min
CU-t
Current coolant temperature in °C on the cooling unit
(with built-in OPT/i CU flow temperature sensor option)
130
