Connecting the mains cable
Safety
WARNING!
Danger due to work that has been carried out incorrectly.
This can result in serious injury and damage to property.
▶
The work described below must only be carried out by trained and qualified
personnel.
▶
Observe national standards and directives.
CAUTION!
Danger due to improperly prepared mains cable.
This can cause short circuits and damage.
▶
Fit ferrules to all phase conductors and the ground conductor of the
stripped mains cable.
General If no mains cable is connected, a mains cable that is suitable for the connection
voltage must be fitted before commissioning.
Strain-relief devices for the following cable cross-sections are fitted to TPS 270i
C power sources:
Power source External diameter of cable
TPS 270i C /nc 14 - 16 mm
TPS 270 i C / S/nc 14 - 16 mm
TPS 270i C /MV/nc 14 - 18.5 mm
Strain-relief devices for other cable cross-sections must be designed accord-
ingly.
Stipulated mains
cables
Power source Mains voltage Cable cross-section
USA / Canada * Europe
TPS 270i C /nc
3 x 380 V
3 x 400 V
3 x 460 V
AWG 14 4G 2.5 mm²
TPS 270i
C /MV/nc
3 x 200 V
3 x 230 V
AWG 12 4G 2.5 mm²
3 x 380 V
3 x 400 V
3 x 460 V
AWG 14 4G 2.5 mm²
TPS 270i C /S/nc
**
3 x 460 V
3 x 575 V
AWG 14 -
* Cable type for USA / Canada: Extra-hard usage
** Power source without CE mark; not available in Europe
