Connecting the
welding torch
1
Before connecting the welding torch, check that all cables, lines and hosep-
acks are undamaged and properly insulated.
2
Open the wire-feed unit cover
3
Inserting/repla-
cing feed rollers
In order to achieve optimum wire electrode feed, the feed rollers must be suit-
able for the diameter and alloy of the wire being welded.
NOTE!
Only use feed rollers that match the wire electrode.
An overview of the feed rollers available and their potential application areas can
be found in the Spare Parts Lists.
CAUTION!
Danger from feed roller holders flying upwards.
This can result in injuries.
▶
When unlocking the lever, keep fingers away from the area to the left and
right of the lever.
1 2
67
EN
