Fronius TPS/i COMPACT - Process Parameters for Process MIX

Process para-
meters for Pro-
cess Mix
The following process parameters for mixed processes can be set under "Process
mix":
(1)
(2) (3) t [ms]
I [A]
PMC mix
v
D
[m/min]
Mixed process between PMC and LSC welding process. A cold LSC process phase follows a hot PMC
process phase as part of a cycle.
(1)
(2) (3)
I [A]
PMC mix drive
v
D
[m/min]
t [ms]
Mixed process between PMC and wire movement reversal using a PushPull drive unit. A cold low
power phase with calibration movement follows a hot PMC process phase.
(1)
(2) (3)
t [ms]
I [A]
CMT mix
v
D
[m/min]
Mixed process between CMT and PMC welding process. Cold CMT process phases follow hot PMC
process phases.
(1) Lpc - Lower power correction
(2) Lptc - Lower power time correction
(3) Hptc - Upper power time correction
vd
Wire speed
Is taken from the welding parameters
Setting range: 1.0 - 25.0 m/min (40 - 985 ipm)
123
