Design of the
brake
WARNING!
Danger from incorrect installation.
This can result in severe personal in-
jury and damage to property.
▶
Do not dismantle the brake.
▶
Maintenance and servicing of
brakes is to be carried out by
trained, qualified personnel only.
The brake is only available as a com-
plete unit.
This illustration is for information pur-
poses only.
Performing R/L
alignment
IMPORTANT! For optimum welding results, the manufacturer recommends per-
forming an R/L alignment when starting the device for the first time and when
any changes are made to the welding system.
