Spot and stitch welding
Spot welding Spot welding is used on welded joints on overlapped sheets that are only access-
ible on one side.
Spot welding can be carried out in the following welding processes:
PULSE SYNERGIC | SYNERGIC | MANUAL | LSC/PMC | SP (CMT)
1
Select the desired welding process by pressing the "Welding process" button
2
Select the MODE by pressing the "Mode" button
"Spot" appears briefly on the display.
3
Setup menu / Process parameters / Spot welding
4
Press the right adjusting dial
The SPt (spot welding time) parameter is shown.
5
Enter the desired value for the spot welding time: press and turn the right ad-
justing dial
Setting range: 0.1 - 10.0 s
Factory setting: 1.0 s
6
Confirm the value by pressing the right adjusting dial
NOTE!
4-step mode is assigned as standard for spot welding.
Press the torch trigger - Spot welding process runs until the end of the spot
welding time - Press again to stop the spot welding time prematurely
▶
The spot welding setting can be changed to 2-step in the Setup menu under
Settings / System / SPm
(more information on 2-step and 4-step mode for spot welding starts on
page 132)
7
Select the filler metal, wire diameter and shielding gas
8
Open the gas cylinder valve
9
Set the shielding gas flow rate
WARNING!
Danger due to emerging wire electrode.
This can result in serious personal injuries.
▶
Hold the welding torch so that the tip of the welding torch points away from
the face and body.
▶
Wear suitable protective goggles.
▶
Do not point the welding torch at people.
▶
Ensure that the wire electrode can only intentionally make contact with elec-
trically conductive objects.
10
Spot welding
Procedure for producing a welding spot:
86
