Fronius TPS/i COMPACT - Setting the Standards; Setting Hold Mode; Setting the Display Brightness

Setting the
standards
1
Select Setup menu / Settings / View / Standard
2
Press the right adjusting dial
The first of the available standards is displayed.
3
Select the desired standard by turning the right adjusting dial:
-
CEN
Name of filler metal according to European standards
(e.g. AlMg 5, CuSi3, Steel, etc.)
-
AWS
Name of filler metal according to the American Welding Society Stand-
ard
(e.g. ER 5356, ER CuSi-A, ER 70 S-6, etc.)
4
Press the right adjusting dial to set the standard
5
To exit the Setup menu, press the "Welding process" and "Mode" buttons at
the same time
Setting hold
mode
1
Select Setup menu / Settings / View / Hold-M.
2
Press the right adjusting dial
The first of the available hold modes is displayed.
3
Turn the right-hand dial to select the desired display of the welding data at
the end of welding:
-
Hold
The current actual values at the end of welding are displayed.
-
Mean
The mean values over the entire main current phase are displayed.
4
Press the right adjusting dial to set the standard
5
To exit the Setup menu, press the "Welding process" and "Mode" buttons at
the same time
Setting the dis-
play brightness
1
Select Setup menu / Settings / View / UIBS
UIBS = User interface brightness settings
2
Press the right adjusting dial
The value for the display brightness is shown.
3
Select the desired display brightness by turning the right adjusting dial (1 - 4)
4
Press the right adjusting dial to apply the value
5
To exit the Setup menu, press the "Welding process" and "Mode" buttons at
the same time
