Welding para-
meters for
manual metal
arc welding
The following welding parameters can be set and displayed for manual metal arc
welding:
using the left adjusting dial:
Main current
1)
in A
Setting range: depends on the power source available
Before the start of welding, the machine automatically displays a standard value
based on the programmed parameters. The actual value is displayed during weld-
ing.
using the right adjusting dial:
Arc-force dynamic
to influence the short-circuiting dynamic at the instant of droplet transfer
Setting range: 0 - 100
Factory setting: 20
0 ... soft and low-spatter arc
100 ... harder and more stable arc
101
