Output voltage range according to
standard characteristic (U
2
)
MIG / MAG
TIG
Rod electrode
14.2 - 27.5 V
14.1 - 20.8 V
20.4 - 30.8 V
Open circuit voltage (U
0
peak/U
0
r.m.s)
66 V
Protection class IP 23
EMC emission class A
Dimensions L x W x H 687 x 276 x 445 mm
27.0 x 10.9 x 17.5 in.
Weight 33.2 kg
73.1 lb.
Max. noise emission (LWA) 69 dB (A)
Max. shielding gas pressure 7 bar
101.5 psi
Wire speed 1 - 25 m/min
40 - 980 ipm
Wire drive 4-roller drive
Wire diameter 0.8 - 1.6 mm
0.03 - 0.06 in.
Wirespool diameter max. 300 mm
max. 11.8 in.
Wirespool weight max. 19.0 kg
max. 41.9 lb.
Idle state power consumption at 400
V
35.9 W
Power source efficiency
at 270 A / 30.8 V
90%
The wirefeeder for the TPS 270i C is integrated in the power source.
1) Interface to a 230/400 V and 50 Hz public grid
