WARNING!
Danger due to emerging wire electrode.
This can result in serious personal injuries.
▶
Hold the welding torch so that the tip of the welding torch points away from
the face and body.
▶
Wear suitable protective goggles.
▶
Do not point the welding torch at people.
▶
Ensure that the wire electrode can only intentionally make contact with elec-
trically conductive objects.
NOTE!
The wire electrode can be threaded by pressing a wire threading button present
in the welding system or by pressing the torch trigger.
3
4
Notes on wire threading
If contact is made with the earth during wire threading, the wire electrode is
automatically stopped.
When the torch trigger is pressed once, the wire electrode moves forwards 1 mm.
With a push wire feeding system:
If contact is made with the workpiece during threading, the wire play in the inner
liner is measured. If the measurement is successful, a wire play value is entered
in the event logbook, which is used to control the system.
72
