10 Setups
362
Setups
10
îš„Secondary Server IP Address
Set the secondary server IP address, using values from 0 to 255.
Note • You can set this when [Secondary Server Setup] is [By IP Address].
• 224.XXX.XXX.XXX to 255.XXX.XXX.XXX and 127.XXX.XXX.XXX cannot be set.
îš„Secondary Server Name
Set the server name for the secondary server. You can enter up to 64 characters.
Note • You can set this when [Secondary Server Setup] is [By Server Name].
Secondary Server Port Number
Set the directory server (secondary server) port number in the range from in the range
from 1 to 65535.
Login Name
Set the login name for access to the directory server. However, set this only when
authentication is required for the directory service. Do not make the setting when
authentication is not required.
When setting the login name, you can enter up to 256 characters.
Password
Set a password for access to the directory server. However, set this only when
authentication is required for the directory service. Do not make the setting when
authentication is not required.
When setting the password, you can enter up to 32 characters.
Search Root Entry DN
You can enter the search root character string with up to 256 characters.
Scope of Search from Root Entry
Select the search range from the search root.
îš„Root entry only
Searches the root level only.
îš„One level below root entry only
Searches from the root, as far as one level below.
îš„All levels below root entry
Searches from the root, including all levels below.
Object Class of Search Target
You can enter the search target object classes with up to 32 characters.
Server Application
You can select the software used for the directory server, from [Microsoft Active
Directory], [Novell NetWare 5.*], and [Other Applications].
Attribute Type of Recipient Name
Set the recipient name attribute type. You can enter up to 32 characters.
To Next Page
