6.2 Stapler Faults 239
Staple Jams in Staple Cartridge
(for C3 Finisher and C3 Finisher with Booklet Maker)
This section describes how to clear staple jam occurred in the staple cartridge of the C3 Finisher
(optional) and the C3 Finisher with Booklet Maker (optional).
1. After confirming that the printer is not
performing any operation, open the finisher
front cover.
2. With grasping the lever R1 of the staple
cartridge holder, pull out the holder to the
right, towards you.
3. With grasping the orange lever, pull out the
staple cartridge.
Note
• The staple cartridge is firmly inserted. A slight force is
required to pull the cartridge out of the finisher.
• When the C3 Finisher Staple Unit 65 Sheets is installed, pull
down the orange lever, and pull out the staple cartridge.
4. After removing the staple cartridge, check
inside of the finisher for any remaining
staples.
To Next Page
