302 7 Maintenance
Replacing Staple Cartridge
When the staple cartridge needs to be replaced, a message appears on the display. When this
message appears, load a new staple case into the staple cartridge.
Important
• The use of staple cartridges not recommended by Fuji Xerox may degrade quality and performance. Use only
staple cartridges recommended by Fuji Xerox.
Replacement Procedure (Staple Cartridge R1)
When the message Staple Cartridge R1 is displayed on the display, follow the instruction below
to replace the staple cartridge with a new one.
1. After confirming that the printer is not
performing any operation, open the finisher
front cover.
2. With grasping the lever R1 of the staple
cartridge holder, pull the holder to the right,
towards you.
3. With grasping the orange lever, pull out the
staple cartridge.
Note
• The staple cartridge is firmly inserted. A slight force is
required to pull the cartridge out of the finisher.
• When the C3 Finisher Staple Unit 65 Sheets (optional) is
installed, pull down the orange lever, and pull out the staple
cartridge.
