74 3 Printing
3.3 Printing on Custom Size Paper
This section explains how to print on custom size paper.
The following are the sizes of paper that can be loaded into the paper trays.
Loading Custom Size Paper
The settings for custom size paper are similar to those for standard size paper. For more
information, refer to "4.2 Loading Paper" (P. 127).
Registering Custom Size Paper
Custom size paper needs to be registered with the print driver before it can be used. The following
example shows how to do this with Windows 7.
When loading custom size paper in tray 1 to 4 (Trays 3 and 4 are optional.), use the control panel
to configure the paper size settings. For information on how to configure settings on the control
panel, refer to "Setting the Paper Sizes of Trays" (P. 134).
Important
• Make sure the paper size settings are configured correctly with the print driver or on the control panel. Setting the
wrong paper size can cause malfunction of the printer.
Note
• Only users with administrator level access authority can change settings. Users without administrator privileges
can only view settings.
• Changing the settings on the [Custom Paper Size] dialog box while the printer is being used as a local printer can
affect settings for other printers on your computer. Changing settings when the printer is a network printer can
affect other network-shared printers on other computers over the network. This is because the printer uses its own
form database when it is local, while it uses the form database of a server that has a print queue when it is
networked.
1. On the [Start] menu, select [Devices and Printers] (select [Printer] or [Printers and Faxes]
depending on the OS) and display the properties of the printer being used.
Bypass Tray
Trays 1 to 4 (Two Tray Module)
(Trays 3 and 4 are optional.)
Width:
89 - 297 mm
Length:
98 - 432 mm
Paper feed direction
Width:
140 - 297 mm
Length:
182 - 432 mm
Paper feed direction
To Next Page
