304 7 Maintenance
2. Pull out the booklet unit.
3. With grasping the lever of the booklet staple
cartridge, push the booklet staple cartridge
downward. Then, pull out the booklet staple
cartridge upwards.
4. Press the orange buttons on the right and left
sides of the booklet staple cartridge (1), and
open the cover (2).
5. Pinch the right and left sides of the empty
staple case (1), and pull out the empty staple
case from the staple cartridge.
Important
• The staple case cannot be removed when the staples are
remained in the staple case. Forcibly removing the staple
case may cause machine malfunction.
6. Insert the new staple case (1), and push the
rear side of the new staple case into the staple
cartridge.
To Next Page
