172 U41117-J-Z125-7-76
Function bar GXCC
Information
Mirroring
Whether the mirror function is enabled or disabled in CentricStor is specified here.
The attributes of a RAID system with the mirror function enabled, whether and
how it is mirrored, are defined by the assignment of the LUNs during RAID
configuration.
Configuration window
In the table the columns represent the RAIDs and the rows represent the LUNs (the rows
can also contain disk numbers in the case of internal RAIDs). The file systems are
contained in the cells.
The print color indicates the mirror status:
black Not mirrored
blue Mirrored
The cells are color coded:
white The conditions have been recognized. However, the file system is not yet
configured.
green The file system is configured and mounted on all ISPs.
red The file system is configured but has not been mounted due to an error.
yellow The file system is configured but has been mounted on only some of the ISPs.
In Observe or User mode, the checkboxes cannot be modified by the user.
Mouse functions in the configuration window
Mouse click
Detailed information on the cell or RAID system selected is displayed in the infobox to
the right.
After you click on the “mirrored” or “unmirrored” header field all file systems in the
column are selected.
1. Left mouse click
2. Shift key + left mouse click
Clicking on one of the cells with the shift-key held down and then clicking on another
cell causes the entire range to be selected. The selection is made for columns.
Ctrl key + left mouse click
Clicking on one of the cells with the Ctrl-key held down will result in a cell being added
(or removed) from a range.
i
