U41117-J-Z125-7-76 237
7 Global Status
7.1 General
The Global Status Monitor outputs all important operating data in graphical format, and
allows you to display important system data over configurable periods.
There are several options for starting “Global Status”:
– using the optional start parameter -globstat parallel to GXCC
– using the corresponding button on the button bar of the GCXX window or
– using the function bar: Tools ➟ Global Status
– from the Root menu on the CentricStor console
The Global Status Monitor is independent of GXCC and must be terminated separately.
If there is no connection to an InfoBroker when Global Status starts up, a selection window
appears. You proceed here as described in the section “Unit” on page 147. You can use it
to select either the same CentricStor you are currently working with under GXCC or a
different one. The same unit file is used as for the GXCC unit selection.
If you select the same CentricStor to which GXCC is connected, you can then
terminate GXCC and restart it again with a mouse click (see section “Global
eXtended Control Center” on page 242).
i
