U41117-J-Z125-7-76 263
Global Status History data
The button bar below these options allows you to select the functions “Exit” and “Redraw”:
If you have selected a long recording period (e.g. months) a very large volume of
data must be analyzed and transferred. In the wait time you are offered an info box
containing the “CANCEL” button.
You should click on this button if you have accidentally selected this long recording
period. The repeated calling of large data volumes in particular can have a negative
effect on the operating behavior of CentricStor.
Hardcopy
You can print the diagrams using » File » Print in the function bar (page 239) or, if “Global
Status” is running on Windows, with the function button available in the button bar
(page 246).
7.6.1.4 Selecting the presentation mode
After the diagram has been built up some time diagrams enable you to specify (function bar
» Mode) whether the the maximum value (max), the spread (min/max) or the average value
(average) should be recorded for each display period. If you select min/max the maximum
and minimum values are separated by a slash.
Redraw: Draws the diagram with the current settings
Exit
i
