366 U41117-J-Z125-7-76

File viewer XTCC

8.5.8.5 Tab Stop Interval

In text files with tabulators the tab stop interval can change. The “default” generates an

interval of 8 characters with behavior typical for a text editor. For the other values intervals

from 1 .... 20 can be selected with behavior typical for a text editor.

8.5.9 Help

Opens a text window containing operating instructions.
