U41117-J-Z125-7-76 415
XTCC RAID systems
This very extensive information indicates the status of the controllers and the disks. The
displays are self-explanatory. For a more precise interpretation, in particular in the case of
partial failures, please refer to the RAID system manual. The content and presentation
depend on the type of RAID controller.
8.17.2.2 Show Mode Pages (CX500/CX3-20 and FCS80)
Displays the SCSI mode pages in a text window. To interpret the page data, you will need
to refer to the SCSI reference manual and the manual for the RAID system.
8.17.2.3 Show Mode Page Details
The mode pages described in the SCSI standard are displayed in detail in text windows. For
further information refer to the section “Show Mode Page Details” on page 428.
8.17.2.4 Show Log Pages
The SCSI log pages are displayed. This function is not available on all systems.
8.17.2.5 Show Log Page Details
You obtain an itemized display of the log page you selected in the submenu. This function
is not available on all systems.
