U41117-J-Z125-7-76 333
XTCC Function bar
File Selection with input field.
List box used to specify the name under which the PostScript file is to be saved.
Depending on the color selection made under “Mode”, this field is preset with
the file name <path>/outcolor.ps or <path>/outgray.ps, where
<path> is set to the XTCC tmp directory. To print out the configuration, these
files can then be sent to the PostScript printer that supports the corresponding
mode.
Browse Button provided under “Print to File” for opening a dialog box used to change
the directory and specify a name for the file to be saved.
Orientation
Allows you to select the display format within the PostScript file:
Portrait Portrait format
Landscape Landscape format
Auto Automatic selection depending on the page dimensions
Paper Allows you to select the paper format to be used:
A4 210 x 297 mm
Letter 216 x 279 mm
Mode Allows you to select the color mode:
color The PostScript file/printout is created in color mode.
grayscale The PostScript file/printout is created in grayscale mode.
OK Starts the creation of the PostScript file/printout.
Help Opens a text window containing the XTCC help file.
Cancel Closes the print menu without accepting the changes.
Windows Platforms
The platform-specific “Print” menu is used which enables you to control all the required
functions. In the case of “Print to file” the format corresponding to the selected printer is
used.
The display is always adjusted to the paper format selected, taking into account the
page ratio. Any scaling predefined in the printer menu is ignored.
i
