Installing the dummy cover
Figure 37: Installing the dummy cover
â–¶
Insert the dummy cover into the empty bay with the impressed arrow symbol
facing to the left (see circle).
â–¶
Push the dummy cover into its bay until it locks in place.
CAUTION
â–¶
Always install dummy covers into unused bays to comply with
applicable EMC regulations and satisfy cooling requirements.
Concluding steps
No steps needed.
6.5
Replacing a hot-plug PSU
Customer Replaceable
Unit (CRU)
Hardware: 5 minutes
Tools: Phillips PH1 / (+) No. 1 screw driver (for DC PSU -48 V)
The procedure of replacing an AC PSU or a DC PSU differs only in
disconnecting/connecting the power cord.
Power supply unit (PSU)
114 Upgrade and Maintenance Manual RX2530 M6
