Prepare the removing of the PCIe SSD module.
▶
Depending on your configuration and OS: "Shutting down the server" on
page 48.
Removing the defective 2.5-inch PCIe SSD module
▶
Remove the PCIe SSD module, see "Removing a 2.5-inch PCIe SSD
module" on page
150.
▶
If applicable, remove the PCIe SSD from the installation frame, see
"Handling HDDs or SSDs without installation frame" on page
120.
Installing the new 2.5-inch PCIe SSD module
▶
If applicable, install the PCIe SSD in the installation frame, see "Handling
HDDs or SSDs without installation frame" on page 120.
▶
Install the PCIe SSD module, see "Installing a 2.5-inch PCIe SSD module"
on page 148.
Concluding steps
▶
If applicable, "Switching on the server" on page 66.
▶
If applicable, rescan available devices from your OS.
▶
If applicable, "Installing the front cover with lock" on page 66.
7.5.8 Replacing the 8x 2.5-inch HDD backplane
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
Preliminary steps
▶
"Locating the defective server" on page 45.
▶
If applicable, "Removing the front cover with lock" on page
48.
Hard disk drive (HDD) / solid state disk (SSD)
152 Upgrade and Maintenance Manual RX2530 M6
