13.3.3 Installing the ODD
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: – Phillips PH2 / (+) No. 2 screw driver (for cover 2)
–
T
orx Plus 6 screw driver (not valid for Japan)
–
Phillips PH1 / (+) No. 1 screw driver (Japan)
Preliminary steps
▶
"Suspending BitLocker functionality" on page 75.
▶
If applicable, "Removing the front cover with lock" on page
48.
▶
"Shutting down the server" on page 48.
▶
"Disconnecting the power cord" on page 49.
▶
"Getting access to the component" on page 52.
Removing the dummy cover
Figure 226: Removing the dummy cover
Accessible drives
316 Upgrade and Maintenance Manual RX2530 M6
