Liquid cooling configuration
A LC configuration is provided on special release request only.
Figure 308: Quick connectors for LC
1 Quick connector: water outlet 2 Quick connector: water inlet
17.2.3.2 ID, CSS and Global Error indicators
Figure 309: ID, CSS and Global Error indicators
1 ID indicator
2
CSS indicator
3 Global Error indicator
ID indicator (1)
See also "iRMC-related status signals" on page 420.
Appendix A
418 Upgrade and Maintenance Manual RX2530 M6
