Fujitsu PRIMERGY RX2530 M6 User Manual

Figure 41: Installing the 2.5-inch HDD/SSD in the 2.5-inch installation frame (B)
▶
Fasten the 2.5-inch HDD/SSD with four screws.
Removing a 2.5-inch HDD/SSD from a 2.5-inch installation frame
▶
Please proceed in reversed order
.
Concluding steps
No steps needed.
7.3.3 2.5-inch HDD/SSD and 3.5-inch installation frame
Installing or removing the installation frame is only necessary for Japan.
Customer Replaceable
Unit (CRU)
Hardware: 5 minutes
Tools: Phillips PH1 / (+) No. 1 screw driver
Hard disk drive (HDD) / solid state disk (SSD)
RX2530 M6 Upgrade and Maintenance Manual 123

Fujitsu PRIMERGY RX2530 M6 Specifications

General

Form Factor	2U Rack
Chipset	Intel C621A
Processor	Intel Xeon Scalable Processors (3rd Gen)
Memory Type	DDR4
Memory Slots	16
Storage	2.5-inch or 3.5-inch SAS/SATA/NVMe drives
Drive Bays	12 x 2.5" or 3.5"
Network Controller	Intel Ethernet Controller (optional)
Expansion Slots	Up to 3 x PCIe Gen4 slots
Power Supply	Redundant hot-plug power supplies, various wattage options available
Management	Fujitsu ServerView Suite
Operating System Support	Windows Server, Linux, VMware
RAID Controller	Optional RAID controllers (LSI MegaRAID)
