7.2 Basic information
The HDD or SSD and the installation frame together make up the HDD module
or SSD module.
The server is shipped with one of the following HDD or SSD subsystems:
–
3.5-inch HDD subsystem
–
2.5-inch HDD/SSD subsystem
–
EDSFF SSD subsystem
3.5-inch HDD subsystem
Up to four 3.5-inch SAS/SA
TA HDD modules can be installed. The HDD
module is connected to the HDD backplane wirelessly
. This allows HDD
modules to be plugged in or pulled out easily.
Hybrid configurations of SAS and SATA HDD modules are supported in
combination with an optional HDD controller.
For information on RAID controllers controlling the HDD modules, see
"Expansion cards and backup units" on page 195.
Hard disk drive (HDD) / solid state disk (SSD)
118 Upgrade and Maintenance Manual RX2530 M6
