Figure 164: Disconnecting the cables
▶
Disconnect the three cables.
Concluding steps
▶
"Reassembling" on page
57.
▶
"Connecting the power cord" on page
62.
▶
"Switching on the server" on page 66.
▶
If applicable, "Installing the front cover with lock" on page 66.
▶
If applicable, update the system information of your server using the Chassis
ID Prom Tool, see "Using the Chassis ID Prom Tool" on page 98.
▶
"Resuming BitLocker functionality" on page 93.
9.6.8 Replacing the internal RAID controller
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Software: 5 minutes
Tools: – Phillips PH1 / (+) No. 1 screw driver
– Phillips PH2 / (+) No. 2 screw driver
Expansion cards and backup units
244 Upgrade and Maintenance Manual RX2530 M6
