Figure 100: Installing the EDSFF SSD module
▶
Insert the EDSFF SSD module into a drive bay and carefully push back as
far as it will go (1).
▶
Close the locking lever to lock the EDSFF SSD module in place (2).
Concluding steps
▶
If applicable, "Switching on the server" on page
66.
▶
If applicable, rescan available devices from your OS.
▶
If applicable, "Installing the front cover with lock" on page 66
.
7.6.3 Removing EDSFF SSD modules
Customer Replaceable
Unit (CRU)
Hardware: 5 minutes
Tools: tool-less
Hard disk drive (HDD) / solid state disk (SSD)
RX2530 M6 Upgrade and Maintenance Manual 179
